Three-dimensional scanning of large steam turbine cabin

'Our company has developed the original products of the times and market demand with its technical strength, and leads the market with technical solutions that are constantly practiced and innovated.' The customer is a well-known 'wind power group' at home and abroad. It is a place to seek technical solutions and use the new 3D scanning technology to obtain 3D data of the new energy turbine cabin.

More +
Sewage treatment equipment fan impeller three-dimensional scanning case

The fan impeller is an important part of the power system in the sewage treatment equipment. A well-known large-scale water treatment equipment manufacturer in China needs to perform three-dimensional scanning on the fan impeller of an imported sewage treatment equipment, and obtain high-precision three-dimensional data to inversely model the fan impeller. Impellers reduce company losses.

More +
Solar mirror

Solar mirror is one of the core components of the trough type high temperature heat collection system, which is divided into glass mirror, ceramic mirror, metal mirror, etc.. Reflector is an important part of the solar heat utilization, and high precision, high reflectivity and high durability constitute the important performance index of the solar reflector.

More +
Nuclear device 3D inspection case

An internationally renowned research institute needs to conduct a comprehensive inspection of the processed nuclear devices and compare the digital patterns of the products. In order to improve the nuclear processing technology and improve quality.

More +
Impeller reverse design

A centrifugal fan relies on input mechanical energy to accelerate gas through a high-speed rotating impeller. A centrifugal fan is composed of a casing, main shaft, impeller, bearing transmission mechanism, and motor. The speed of the fan can not only cancel throttling losses, but also ensure that the fan always operates in an efficient area, thus greatly saving electricity. This reflects the new trend of current industrial production.

More +
Water turbine bucket defect detection

Most of the impulse turbines that have been operated for many years have cracks in their buckets, and some will also have bucket dropping, which has seriously affected the safety and economic operation of the hydropower station. However, most of the bucket repairs are conducted on site, the treatment process is rough, and the quality is not guaranteed, which brings hidden dangers to the operation of the unit after maintenance.

The personnel of the project team decided to use the hand-held 3D scanner to carry out all-round defect detection on the hydraulic turbine bucket

More +
Three-dimensional inspection of turbine volute

The turbine volute is one of the commonly used equipment in hydropower plants at present. The huge energy generated by the drop of high water level makes the volute undergo regular maintenance. There are many disadvantages in the previous maintenance. In order to further save the maintenance time and cost, the manufacturer decided to use the Hualang handheld 3D scanner for inspection:

More +
3D Scanning of Leaf

The surface of the blade workpiece is a complex curved surface. In the quality inspection, due to the influence of the shape and structure of the workpiece, the traditional industrial inspection method is used to directly detect the workpiece, which can no longer meet the increasing demand of industrial inspection. The types of data that can be inspected are limited, and it is impossible to accurately and quickly determine whether the data is It meets the design requirements, and the detection process takes a long time.

More +
Wind blade 3D inspection

The design of the blades in a wind turbine can directly affect the efficiency of wind energy conversion. Good design, reliable quality and superior performance are the decisive factors to ensure the normal and stable operation of the unit. It directly affects its annual power generation and is an important part of wind energy utilization. 3D scanning technology is used to quickly obtain 3D data of the inspection position of the blade, and through data analysis and comparison, we can understand the existence of the problem and make timely maintenance to ensure the operation of the work.

More +
