Geomagic Design X is the most comprehensive reverse engineering software in the industry, which combines feature-based CAD modeling with 3D scanning data processing, allowing you to create editable, feature-based CAD models that are compatible with your existing CAD software.

Expand your design capabilities

Instead of starting with a blank screen, start with data created in the real world. Geomagic Design X is an easy way to create editable, feature-based CAD models from a 3D scanner and integrate them into your existing engineering design workflow.

Accelerate time to market

Reduce the time it takes for a product to go from idea to finished design by days or even weeks. Scan prototypes, existing parts, molds, or related objects and create designs in a fraction of the time required to manually measure and create CAD models from scratch.

Enhance your CAD environment

Seamlessly integrate 3D scanning into your regular design process to help you be more productive and save time on the job. Geomagic Design

Leverage existing assets

Many designs are inspired by other designs. Easily scan an object or model into a CAD system. Learn this object or model for reuse. and improve it. Easily rebuild old parts into current CAD data to create drawings and product designs.

Accomplish the impossible

Create products that can only be designed through reverse engineering, and parts that need to fit perfectly with the human body. Create components that integrate seamlessly with existing products. Recreate complex geometries that cannot otherwise be measured.

Cut costs

If you model both built and designed parts, you can save a lot of money and time. Deform the CAD model to fit the 3D scan. Reduce tooling duplication costs by using actual part geometry to correct CAD and eliminate part springback issues. Reduce costly errors caused by poor fit with other components.

Works seamlessly with existing CAD

Geomagic Design X connects directly to popular CAD software, including SOLDWORKSe, Siemens Nxo, Solid Edge, Autodesk Inventore and PTC Creo. Design X uses unique LiveTransfer technology to transfer complete models, including feature trees, so you can quickly create solid and surface models from 3D scans.

Combines powerful functionality and flexibility

Geomagic Design X is purpose-built for converting 3D scan data into high-quality feature-based CAD models. It can do things other software cannot, including extracting automated and guided solid models, fitting precise surfaces to organic 3D scans, editing patches, and processing point clouds. Now you can scan almost any object and create a design that's ready for manufacturing.

High-intensity functionality for demanding projects

Geomagic Designx's expanded toolset combines CAD tools, industry-leading scan processing tools, and all the firepower you need to tackle your most challenging projects. It can handle billions of scan points and has complete features to solve data problems, so you can skip scan cleanup and start creating CAD models immediately.

Runs like CAD software

If you can design in CAD, you can start working with Geomagic Design X right away. A completely revamped user interface and workflow tools make it easier than ever to create designed and built 3D CAD and model data quickly and accurately.

Features

Direct 3D scanner control tools for many of today’s most popular devices

Supports import of over 60 file formats including polygons, point clouds and CAD

Professionally handles large-scale patch and point cloud data alignment, calculation and optimization, and patch construction

Easy-to-use patch repair tools provide smart brushes with automatic hole filling, smoothing control, patch optimization, re-wrapping and touch-up tools to automatically extract feature-based solids and surfaces directly from 3D scans

Quickly create solids or surfaces, similar to creating in CAD

Automated Precision Analysis™ tools compare and validate surfaces, solids and sketches against raw scan data. Live Tronsfer…enables data export to industry-leading CAD systems

Industry-leading “accurate” surface creation method converts organic shapes into accurate CAD models

Supports multiple ways of exporting CAD or polygon files in neutral data formats
